Description
DIMENSIONS
- ATX Form Factor
- 30.5cm x 24.4cm
CPU
- Support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series, Ryzen™ 3000 Series and Ryzen™ 3000 G-Series Processors
- Processor socket AM4
- AMD B550 Chipset
MEMORY
- 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
- Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
- Dual channel memory architecture
- Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules*
- ECC memory (ECC mode) support varies by CPU
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- Support for Extreme Memory Profile (XMP) memory modules
EXPANSION SLOT
- 1x PCI Express x16 slot (PCIEX16), integrated in the CPU:
- AMD Ryzen™ 5000 Series and Ryzen™ 3000 Series Processors support PCIe 4.0 x16 mode
- AMD Ryzen™ Ryzen™ 5000 G-Series and Ryzen™ 4000 G-Series Processors support PCIe 3.0 x16 mode
- For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
- 1x PCI Express x16 slot (PCIEX4), integrated in the Chipset:
- Supporting PCIe 3.0 x4 mode
- 1x PCI Express x1 slot (PCIEX1), integrated in the Chipset:
- Supporting PCIe 3.0 x1 mode
AUDIO
- Realtek® ALC1200 codec
- High Definition Audio
- 2/4/5.1/7.1-channel
- Support for S/PDIF Out
STORAGE
- AMD Ryzen™ 5000 Series and Ryzen™ 3000 Series Processors
- 1x M.2 connector (M2A_CPU), integrated in the CPU
- Type 2242/2260/2280/22110 SSDs
- PCIe 4.0 x4/x2 SSDs
- 1 x M.2 connector (M2B_SB), integrated in the Chipset
- Type 2242/2260/2280/22110 SSDs
- PCIe 3.0 x4/x2 SSDs
- 4x SATA 6Gb/s connectors, integrated in the Chipset:
- Support for RAID 0, RAID 1, and RAID 10
- 1x M.2 connector (M2A_CPU), integrated in the CPU
LAN
- Realtek® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
WI-FI & BLUETOOTH®
- Intel® Wi-Fi 6 AX200 (For PCB rev. 1.0)
- WIFI a, b, g, n, ac with wave 2 features, ax, supporting 2.4/5 GHz Dual-Band
- BLUETOOTH 5
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
- AMD Wi-Fi 6E RZ608 (MT7921K) (For PCB rev. 1.1 / 1.2)
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.2
- Support for 11ax 80MHz wireless standard and up to 1.2 Gbps data rate
- Intel® Wi-Fi 6E AX210 (For PCB rev. 1.3)
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.3
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
- Realtek® Wi-Fi 6E RTL8852CE (For PCB rev. 1.4 / 1.5)
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.2
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
(Actual data rate may vary depending on environment and equipment.)
POWER CONNECTORS
- 1x 24-pin ATX main power connector
- 1x 8-pin ATX 12V power connector
INTERNAL USB CONNECTORS
- 1 x USB Type-C™ port, with USB 3.2 Gen 1 support
- 1 x USB 3.2 Gen 1 header (Supports additional 2 USB 3.2 Gen 1 ports)
- 2 x USB 2.0/1.1 headers (Supports additional 4 USB 2.0/1.1 ports)
FAN CONNECTORS
- 1 x CPU fan header
- 1 x water cooling CPU fan header
- 3 x system fan headers
SYSTEM CONNECTORS
- 1 x front panel header
- 1 x front panel audio header
- 1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)
- 1 x Clear CMOS jumper
- 1 x Q-Flash Plus button
LED FEATURES
- 1 x CPU cooler LED strip/RGB LED strip header
- 2 x addressable LED strip headers
- 2 x RGB LED strip headers
BACK PANEL PORTS
- 1 x DisplayPort
- 1 x HDMI port
- 2 x SMA antenna connectors (2T2R)
- 2 x USB 3.2 Gen 2 Type-A* / USB 3.2 Gen 1 ports (red)
- For AMD Ryzen™ 5000 Series/3000 Series Processors only.
- 3 x USB 3.2 Gen 1 ports
- 2 x USB 2.0/1.1 ports
- 1 x Q-Flash Plus button
- 1 x RJ-45 port
- 1 x optical S/PDIF Out connector
- 5 x audio jacks
