Description
CPU
- Supports Intel® Core™ Ultra Processors (Series 2)
- Intel LGA 1851 Socket
- Intel Z890 Chipset
MEMORY
- 4x DDR5 UDIMM, Maximum Memory Capacity 256GB
- Support up to 9066+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)
- Dual channel memory architecture
- Non-ECC, un-buffered DDR5 memory supports On-Die ECC function
- Supports Intel® Extreme Memory Profile (XMP) memory module
EXPANSION SLOT
- CPU:
- 1 x PCIe 5.0 x16 slot
- Chipset:
- 1 x PCIe 4.0 x16 slot (supports x4 mode)
- 1 x PCIe 4.0 x4 slot
- 2 x PCIe 4.0 x1 slots
AUDIO
- Realtek® ALC1220P Codec
- 7.1-Channel High Definition Audio
STORAGE
- CPU:
- M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
- M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
- Chipset
- M.2_3 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode)
- M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
- 4 x SATA 6Gb/s ports
LAN
- 1x Intel® 2.5Gb Ethernet
WI-FI & BLUETOOTH®
- Wi-Fi 7
- 2×2 Wi-Fi 7 (802.11be)
- Supports 2.4/5/6GHz frequency band**
- Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.
- Bluetooth® v5.4
*Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries
POWER CONNECTORS
- 1 x 24-pin Main Power connector
- 2 x 8-pin +12V CPU Power connector
INTERNAL USB CONNECTORS
- 1 x USB 20Gbps connector (supports USB Type-C® )
- 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
- 2 x USB 2.0 headers support 4 additional USB 2.0 ports
FAN CONNECTORS
- 1 x 4-pin CPU Fan header
- 1 x 4-pin CPU OPT Fan header
- 1 x 4-pin AIO Pump header
- 4 x 4-pin Chassis Fan headers
SYSTEM CONNECTORS
- 1 x Clear CMOS header
- 1 x Chassis Intrusion header
- 1 x COM Port header
- 1 x Front Panel Audio header (F_AUDIO)
- 1 x 10-1 pin Front System Panel header
- 1 x Thunderbolt™ (USB4®) header
LED FEATURES
- 1x 4-pin RGB LED connector
- 3x 3-pin A-RAINBOW V2 (ARGB Gen2) LED connectors
- 4x EZ Debug LED
- 1x EZ Digi-Debug LED
BACK PANEL PORTS
- 1 x Thunderbolt™ 4 USB Type-C® port
- 1 x USB 20Gbps port (1 x USB Type-C® with DP Alt mode)
- 3 x USB 10Gbps ports (3 x Type-A)
- 3 x USB 5Gbps ports (3 x Type-A)
- 1 x DisplayPort
- 1 x HDMI™ port
- 1 x Wi-Fi module
- 1 x Intel® 2.5Gb Ethernet port
- 5 x Audio jacks
- 1 x Optical S/PDIF out port
- 1 x BIOS FlashBack™ button
