Description
CPU
- Intel® Socket LGA1700 for Intel® Core™ 14th & 13th Gen Processors, Intel® Core™ 12th Gen, Pentium® Gold and Celeron® Processors
- Intel® Z790 Chipset
MEMORY
- 4 x DIMM slots, max. 192GB, DDR5
- 8000+(OC) / 7800+(OC) / 7600(OC) / 7400(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5800(OC) / 5600 / 5400 / 5200 / 5000 / 4800MHz Non-ECC, Un-buffered Memory*
- Dual channel memory architecture
- Supports Intel® Extreme Memory Profile (XMP) memory module
EXPANSION SLOT
- Intel® CoreTM Processors (14th & 13th & 12th Gen)
- 2 x PCIe 5.0 x16 slots (support x16 or x8/x8 modes)**
- Intel® Z790 Chipset
- 1 x PCIe 4.0 x4 slot
- Please check the PCIe bifurcation table on the support site
- M.2_1 shares bandwidth with PCIEX16 (G5)_2. When M.2_1 is enabled, PCIEX16 (G5)_2 will be disabled and PCIEX16 (G5)_1 will run x8 only.
AUDIO
- ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback
- SupremeFX Shielding Technology
- ESS® ES9218 QUAD DAC
- Gold-plated audio jacks
- Rear optical S/PDIF out port
STORAGE
- Total supports 5 x M.2 slots and 4 x SATA 6Gb/s ports*
- Intel® CoreTM Processors (14th & 13th & 12th Gen)
- M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode.)**
- M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode.)
- Intel® Z790 Chipset**
- M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
- M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
- M.2_5 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
- 4 x SATA 6Gb/s ports
- * Intel® Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10.
- ** M.2_1 shares bandwidth with PCIEX16 (G5)_2. When M.2_1 is enabled, PCIEX16 (G5)_2 will be disabled and PCIEX16 (G5)_1 will run x8 only.
LAN
- 1 x Intel® 2.5Gb Ethernet
WI-FI & BLUETOOTH®
- Intel® Wi-Fi 7
- 2×2 Wi-Fi 7 (802.11be)
- Supports 2.4/5/6GHz frequency band
- Support Wi-Fi 7 320MHz bandwidth, up to 5.76Gbps transfer rate.
- Bluetooth® v5.4
- Compatible with Windows 11 or later.
- Wi-Fi 7 MLO(Multi-link Operation) full functions support will be ready in Windows 11 2024 Platform (Windows 11 24H2) or later.
- Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries.
- The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer’s website for the latest specifications.
POWER CONNECTORS
- 1 x 24-pin main power connector
- 2 x 8-pin +12V power connector
- 1 x 8-pin PCIe power connector
INTERNAL USB CONNECTORS
- 1 x USB 20Gbps connector (supports USB Type-C®)
- 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports
- 2 x USB 2.0 headers support 4 additional USB 2.0 ports
FAN CONNECTORS
- 1 x 4-pin CPU Fan header
- 1 x 4-pin CPU OPT Fan header
- 1 x 4-pin AIO Pump header
- 4 x 4-pin Chassis Fan headers
- 1 x W_PUMP+ header
- 1 x 2-pin Water In header
- 1 x 2-pin Water Out header
- 1 x 3-pin Water Flow header
SYSTEM CONNECTORS
- 1 x FlexKey button
- 1 x Front panel audio header (F_AUDIO)
- 1 x Start button
- 1 x ReTry button
- 1 x 10-1 pin system panel header
- 1 x Thermal sensor header
- 1 x CPU over voltage jumper
- 1 x Alternative PCIe mode switch
LED FEATURES
- 3 x Addressable Gen 2 headers
- 1 x AURA RGB header
BACK PANEL PORTS
- 2 x Thunderbolt™ 4 USB Type-C® ports
- 6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C®)
- 4 x USB 5Gbps ports (4 x Type-A)
- 1 x HDMITM port
- 1 x Wi-Fi Module
- 1 x Intel® 2.5Gb Ethernet port
- 5 x Gold-plated audio jacks
- 1 x Optical S/PDIF out port
- 1 x BIOS FlashBack™ button
- 1 x Clear CMOS button
